In today’s competitive landscape, choosing the right industrial motherboard can significantly boost productivity, streamline operations, and enable faster, more efficient outcomes across various industries.
In light of that, Avalue introduces its Intel Panther Lake H Core Ultra (Series 3) H Series Processors motherboard.
Avalue’s EMX-PTLP supports up to 64GB of DDR5 7200MHz SoDIMM/CSoDIMM max. memory, delivering a significant leap in data processing speeds. Optimised for the burgeoning AI market, the board delivers up to 180 TOPS of AI performance. With the integration of PCIe 5.0, users benefit from doubled bandwidth and ultra-low latency, providing the essential foundation for AI acceleration and high-performance computing (HPC) in embedded applications.
EMX-PTLP is designed for maximum flexibility, the EMX-PTLP offers a rich array of expansion options:
- Expansion slots: a dedicated PCIe Gen5 slot allows for high-speed system scaling
- Wireless & connectivity: complete Key-B/E/M interfaces support M.2 modules, complemented by a SIM card slot or SIM FPC interface for seamless remote device management
- Data security: for storage-intensive tasks, the board supports RAID 0/1 configurations via dual M.2 SSDs, ensuring high-speed data access and enterprise-grade redundancy even when using low-power processors
The EMX-PTLP is a powerful for visual applications, supporting up to four simultaneous displays via HDMI, DisplayPort, and USB4 Type-C. It offers resolutions up to 8K and maintains legacy compatibility through eDP and LVDS interfaces, making it adaptable to nearly any industrial display scenario.
To ensure seamless integration into factory ecosystems, the board features:
- Networking: dual Intel LAN (2.5G + 1G) for reliable AOI, DCS, and SCARA robot synchronisation
- I/O Richness: two USB4 (Type-C) ports, four USB 3.2 ports, and five RS-232 serial ports (including two RS-422/485)
- Industrial control: 16-bit GPIO and TPM 2.0 for enterprise security
- Efficiency: a wide 12–24V DC input and an onboard 6W audio amplifier reduce the need for external power converters and peripheral hardware, lowering overall system costs
EMX-PTLP stands out in the compact PC market as a stable, high-compatibility solution. It is purpose-built to withstand complex operating conditions and harsh environments, offering an ideal balance of reliability, long-term availability, and cost-performance for the next generation of industrial automation, with mass production planned for Q3 2026 to support next-generation AI and industrial automation deployments.
Thin Mini ITX EMX-PTLP main features:
- Onboard Intel Core Ultra 5 322, 325, Intel Core Ultra 7 355, 356H, 358H series BGA Processors
- 2 x DDR5 SoDIMM/CSoDIMM (up to 7200MHz / 64GB, non ECC only)
- 1 x HDMI, 3 x DP (2 from USB Type C), 1 x LVDS or eDP (4 independent displays max.)
- 1 x Intel I226LM 2.5G, 1 x Intel? I210AT Gigabit Ethernet
- Realtek ALC888S, TI TPA3113D2PWP Stereo Class-D 6W x 2 Audio Amplifier
- 1 x M.2 Type B 2242/3042/3052, 1 x M.2 Key E 2230, 2 x M.2 Key M 2280
- 1 x PCIe x8 slot
- 2 x USB4 TYPE-C, 4 x USB3.2, 3 x USB 2.0 by pin header
